Rockwell Automation 1794-OF4I Analog Output Module

Type:Analog Output

Model:1794-OF4I

Vendor:Allen-Bradley

Module Class:Flex I/O

Connector Type:DIN Rail Mount

Power Consumption:5W

Operating Range:0 to 10 VDC / 4 to 20 mA

Communication Interface:Modbus RTU

Operating Temperature:-20°C to +60°C

Enclosure Rating:IP20

Dimensions:145mm x 90mm x 45mm

    The Rockwell Automation 1794-OF4I Analog Output Module is designed for applications that demand precise control over analog signals. It offers 4 independent voltage output channels capable of generating voltages from 0 to 10 Vdc or 0 to 20 Vdc, making it suitable for various industrial settings.

    This module supports Modbus RTU communication protocol, ensuring seamless integration with Rockwell’s ControlLogix and RSLogix 5000 systems, providing reliable data exchange and control over the output channels.

    Equipped with robust RS-485 connections, the 1794-OF4I ensures stable communication even in harsh industrial environments. It operates within an extensive temperature range of -40°C to +70°C, allowing it to withstand extreme conditions without compromising performance.

    With a humidity tolerance of 5% to 95% non-condensing, this module is ideal for environments with varying humidity levels, ensuring continuous operation and reliability under diverse climatic conditions.

    The compact design measures 100 x 110 x 110 mm and weighs only 0.4 kg, making it easy to integrate into existing control panels without significantly increasing system footprint or complexity.
