TC101 – GE Module

Operating Range:-40°C to +125°C

PID Control:Yes

Thermocouple Compatibility:J, K, E, T, R, S, B

Resistance Thermometer Compatibility:Yes

Sampling Rate:500ms

CPU Integration:Direct connection to CPU unit

Heater Protection:Burnout detection

Environmental Compliance:CE, UL, CSA, TUV, RoHS compliant

    The OMRON CQM1-TC101 Temperature Control Module is a compact solution designed to provide precise temperature control in industrial automation environments. Its robust design ensures compatibility with various thermocouples and resistance thermometers, allowing for accurate temperature monitoring across diverse applications.

    Equipped with an advanced PID control algorithm, this module offers unparalleled precision in managing temperatures, crucial for maintaining optimal operational conditions in manufacturing processes. The 500ms sampling cycle ensures real-time temperature feedback, enabling immediate adjustments to maintain stability.

    Direct integration with the CPU Unit via RUN/STOP control provides a streamlined approach to temperature management, enhancing efficiency and reducing downtime. The unrestricted CPU unit cycle time allows for customized operation schedules, tailored to specific industrial needs.

    Safety features such as heater burnout detection add an extra layer of protection, safeguarding against potential hazards associated with overheating or malfunctioning heaters. This ensures continuous operation and minimizes risks to equipment and personnel.

    The Auto-Tuning Function simplifies the setup process, saving time and effort required for manual parameter adjustments. This feature optimizes performance, leading to enhanced system reliability and reduced maintenance needs.
