Manufacturer:General Electric
Series:Mark V
Part Number:DS200IMCPG1C
Product Type:AC2000I Power Supply Interface Card
Assembly Type:Normal
Revision:1
Installation Holes:Factory-Drilled (4)
Dimensions:WxHxD (mm): 105x101x100
Weight:0.45 kg
Input Voltage Range:AC 480 V to 690 V
Output Voltage:DC 24 V
Maximum Output Current:15 A
Operating Temperature:-20°C to +60°C
Storage Temperature:-40°C to +85°C
Protection Class:IP20
The DS200IMCPG1C PCB is meticulously designed for seamless integration into GE‘s advanced Mark V Turbine Control Systems, ensuring optimal performance and reliability in demanding industrial environments.
This board is distinguished by its robust Speedtronic control system technology, which enhances system responsiveness and accuracy, making it an indispensable part of high-performance control systems.
With a standard complement of voltage-limiting and storing hardware components, the DS200IMCPG1C ensures stable power supply and protection against overvoltage, crucial for maintaining operational integrity.
The PCB’s factory-drilled installation holes facilitate easy and secure mounting, ensuring compatibility with a wide range of industrial setups.
While the lack of original instructional manuals may present a challenge, the DS200IMCPG1C’s functional product number acts as a powerful tool for detailed hardware insights, enabling users to decode and optimize system configurations for enhanced efficiency.
