Brand:Emerson
Model:IC695CBL010-FD-002
Module Type:Accessories
Cable Type:Duplex Multimode Fiber
Length:10 FT
Fiber Diameter:50/125 µm
Connector Type:ST, SC, or LC
Compliance:RoHS Compliant
Temperature Range:-40°C to +85°C
Data Rate:Up to 1 Gbps
Certifications:CE, FCC, UL
This Emerson fiber optic cable is built to withstand harsh industrial environments, offering durability and reliability for long-distance data transmission. The duplex design allows for simultaneous data transmission in two directions, enhancing communication efficiency. With its robust construction featuring a 50 µm core diameter and 125 µm cladding diameter, this cable supports up to 500 MHz•km bandwidth at 850 nm wavelength, making it suitable for high-speed applications.
The cable is terminated with ST/PC or SC/PC connectors, providing secure and reliable connections. Its operating temperature range from -40°C to +85°C ensures functionality in extreme conditions, while storage temperature limits (-55°C to +90°C) allow for safe handling and storage. This cable complies with international standards such as IEC 60793-2-10, IEC 60793-2-50, and meets RoHS requirements, making it an environmentally friendly choice.
Ease of installation is achieved through the straightforward duplex design, allowing for quick setup and minimal downtime. Use this cable to connect Emerson’s RX3i controllers and other compatible devices in your industrial control system, thereby optimizing your plant’s performance and reliability.
