Material:High-grade FR4 epoxy resin
Dimensions:150mm x 100mm x 5mm
PCB Layer Count:4 Layers
Max Operating Temperature:150°C
Operating Voltage Range:5V – 24V DC
Current Rating:5A
Impedance:50 Ohms
PCB Finish:Gold Plated Solder Mask
Through-Hole Pad Size:0.5mm
Via Size:0.3mm
Engineered for durability and efficiency, the Branson 804-15005-01 PCB Board is meticulously designed to meet the stringent demands of industrial automation. Its robust construction ensures longevity and minimal downtime, even under the most challenging environmental conditions.
The board is crafted from high-quality FR-4 material, renowned for its exceptional thermal stability and electrical insulation properties. This choice of material ensures consistent performance over a wide range of temperatures, making it ideal for use in diverse industrial settings.
Equipped with an advanced power management system, the Branson 804-15005-01 PCB Board efficiently consumes 15 watts, balancing performance and energy savings. This makes it suitable for both high-demand and resource-conscious applications.
Withstanding temperatures from -20°C to +85°C, this board is designed for operational excellence in extreme climates. It can be stored safely at even more demanding temperatures ranging from -40°C to +105°C, offering versatility in manufacturing environments.
Featuring a DC 5V operating voltage and a current rating of 1A, the Branson 804-15005-01 PCB Board offers precise control capabilities. This compatibility with a wide range of industrial components ensures seamless integration into existing systems, enhancing productivity and efficiency.
