Brand:Bachmann
Model:AIC212
Module Type:Industrial Automation Control Module
Input Voltage:18 to 34 VDC
Current Consumption:Max. 1.2 A at 24 V
Nominal Power:17 W
Communication Interface:FASTBUS with 2 FO interfaces
Supported Cables:HCS/PCF up to 150 m or POF up to 40 m
Encoder Power Supply:+5 V or +15 V selectable with jumper
Output Voltage:Low: 0 to 2 V, High: 3 to 34 V, Imax = 10 mA
Counter Resolution:24 bit
Inputs:HEDL (HP/AVAGO interface) / RS422
Outputs:2x Out 150kHz, 2x In INC; 1MHz; RS422; 8x DI 24V
Acceleration Modes:Linear/Sine²/Parable
Positioning Features:2x In INC/SSI; 1MHz; 32bit; RS422 level; INC A, A/B/N; position; gate time; period; velocity
Encoder Supply Voltage:5V / 15V / 24V
Output Voltage Range:±10 V
Output Current:Max. ±2 mA
Diodes:4x DI 24V; trigger; homing
The Bachmann AIC212 is an advanced control module tailored for industrial automation needs. Its robust design allows it to function efficiently under harsh environmental conditions. The module features a FASTBUS master interface with dual fiber optic connections, ensuring fast data transfer and communication over long distances. With its 24-bit counter resolution, it provides precise control capabilities. Users can select the encoder power supply voltage via a jumper switch, offering flexibility in diverse application scenarios. The module’s low and high output voltage settings, along with a maximum current capacity of 10 mA, make it suitable for a variety of control tasks. The AIC212 is an ideal choice for systems requiring accurate positioning and control in manufacturing, automotive, and other industrial environments.
