Model Number:2098-DSD-020X
Brand:Allen-Bradley
Power Rating:1 kW
Continuous Output Current:1 A
Intermittent Output Current:30 A
Operating Voltage Range:100-240VAC
Frequency Range:47-63 Hz
Dimensions:7.8 x 5.68 x 3.89 in (198.12 x 144.27 x 98.1 mm)
Weight:2.1 kg (4.6 lbs)
Energy Absorption Capability:125 Joules @ 115VAC, 51 Joules @ 230VAC
Bus Capacitance:1880 μF
Bus Overvoltage:400 Vdc
Input Requirements:Nominal 18 A rms, 100 A for series A and B, 20 A for series C at 230VAC (0-pk)
The Allen-Bradley 2098-DSD-020X is a standard servo drive designed for applications that demand simple yet effective motion control. It seamlessly integrates with a variety of servo motors, including Allen-Bradley’s renowned Kinetix series, for enhanced performance and efficiency.
Featuring a compact and lightweight design, this drive is optimized for use in space-constrained environments without compromising on power and reliability. Its robust construction ensures longevity and durability in demanding industrial settings.
Equipped with advanced control algorithms, the 2098-DSD-020X supports a wide range of indexing operations and preconfigured motions, making it suitable for a multitude of industries including manufacturing, robotics, and automation. The drive’s ability to handle various motor speeds and torque requirements makes it a flexible solution for diverse applications.
Utilizing a high-capacity bus capacitance and overvoltage protection, the 2098-DSD-020X ensures stable operation even under fluctuating power conditions. Its energy absorption capability mitigates transient power surges, safeguarding against potential damage to connected equipment.
With its integrated communication interface, the drive facilitates seamless integration with PLCs (Programmable Logic Controllers) and other control systems, enabling sophisticated control strategies. Additionally, the indexing capability allows for the storage of pre-defined motion profiles, streamlining setup and operation for repetitive tasks.
