Allen-Bradley 1756-ENBT/A Ethernet/IP Communication Bridge Module

Model Type:Communication Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-ENBT/A

Communication Speed:10/100 Mbps

Communication Protocol:Ethernet/IP

Enclosure Type:Open

Power Supply Compatibility:3 MA at 24 VDC

Mounting:Chassis

Temperature Range:0 – 60 °C

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Connection Cable Compliance:IEEE 802.3 compliant shielded or unshielded twisted pair

Power Dissipation:5.1 W

Isolation:30 V continuous

    The Allen Bradley 1756-ENBT/A module is specifically designed to enhance the capabilities of ControlLogix systems by bridging EtherNet/IP networks, thereby enabling real-time data exchange and control over industrial automation processes.

    Featuring an open type enclosure, this module supports easy installation and maintenance, ensuring reliable operation in various industrial environments.

    With its robust design, the 1756-ENBT/A can withstand harsh conditions, including temperature fluctuations and vibrations, making it suitable for use in demanding industrial settings.

    The module supports high-speed communication, facilitating quick response times and improved system efficiency, which is crucial for optimizing production lines and enhancing overall operational effectiveness.

    Engineered with advanced isolation and environmental protection features, this module ensures stable performance and minimizes potential disruptions caused by external factors, guaranteeing continuous and dependable operation.
