Allen Bradley 1756-CNBR Redundant Bridge Module: ControlLogix, DeviceNet & ControlNet Integration

Model Type:Communication Bridge Module

Model Number:1756-CNBR

Manufacturer:Allen Bradley

Communication Protocol:ControlNet

Redundancy:Yes

Connectors:1 ControlNet BNC connector, 1 NAP RJ-45 8-pin with shield connector

Communication Rate:5 Mbps

Series😀

Enclosure Type:Open

RFI Suppression:Radiated: 10 V/M at 1 KHZ Sine-Wave 80% AM from 80-2000 MHz, Conducted: 10 VRMS at 1 KHZ Sine-Wave 80% AM from 150 KHZ – 80 MHz

Temperature Range:Operating: -40°C to +70°C, Storage: -55°C to +85°C

    The Allen Bradley 1756-CNBR Redundant Bridge Module is engineered for seamless integration into complex industrial control systems, providing enhanced reliability and performance.

    Featuring dual redundant connections to the ControlNet network, this module ensures continuous operation even under unexpected system failures, minimizing downtime and maximizing productivity.

    Built with advanced RFI/EMI suppression technologies, the 1756-CNBR is designed to withstand harsh industrial environments, ensuring stable communication in noisy conditions.

    This module supports high-speed data transfer rates, facilitating efficient data processing and real-time monitoring in fast-paced manufacturing environments.

    Designed for easy installation and maintenance, the 1756-CNBR is compatible with the latest Allen Bradley ControlLogix platforms, offering a future-proof solution for evolving industrial automation needs.
