Model Type:Analog Input Module
Manufacturer:Allen Bradley
Number Of Channels:4
Common Mode Voltage Range:-20 To 20 V
Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS (Maximum)
Input Range:-20 To 20 MA
Absolute Input Current:-30 To 30 MA (Maximum)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Input Range (DC):-10 To 10 VDC – 1 LSB
Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The Allen Bradley 1746SC-IN04VI is engineered for precision, offering high-resolution analog input capabilities ideal for industrial automation systems.
Each of the four input channels supports a wide common mode voltage range, ensuring robust performance under various environmental conditions.
With a maximum absolute input voltage of ±7.5 VDC or ±7.5 VAC RMS, the module is versatile enough for diverse industrial applications.
Featuring a generous input range from -20 to 20 mA, it can accurately capture the nuances of analog signals with exceptional precision.
The inclusion of overvoltage protection ensures reliability and safety in harsh industrial environments, safeguarding against potential damage from electrical spikes.
Designed for easy integration, the 1746SC-IN04VI boasts a flexible current rating, drawing up to 35 mA at 5 V and 85 mA at 24 V, compatible with various backplane configurations.
