Model Type:High Resolution Analog
Number of Channels:2 Inputs & 2 Outputs
Input Range:-20 To 20 V
Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (Max)
Input Current:-30 To 30 MA (Max)
Output Range:-10 To 10 V – 1 LSB
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Current Rating:Backplane Current Draw: 55 MA
Introducing the AB 1746-NIO4V SLC 500 Analog Input/Output Module, a critical component for enhancing the accuracy and reliability of your industrial control systems. This module is specifically engineered to handle demanding analog signal processing tasks, ensuring smooth operation and efficient data transfer.
Equipped with two analog inputs and two voltage outputs, this module offers unparalleled flexibility in managing various types of analog signals. Its ability to process signals in the range of 0 to 20mA and 4 to 20mA for inputs, and 0 to 10V and 0 to 24V for outputs, makes it a versatile choice for a wide array of industrial applications.
Featuring a sampling rate of 250 samples per second, this module ensures real-time response and precision in data acquisition. With its 24VDC power supply, it operates efficiently within a broad temperature range from -10°C to 55°C, ensuring reliable performance under varying environmental conditions.
The inclusion of an RS-485 communication interface allows seamless integration with other control devices, facilitating easy setup and maintenance. Moreover, its IP20 enclosure type provides protection against dust and light splashes, enhancing its durability in industrial settings.
With its compact dimensions of 126mm x 103mm x 55mm, the AB 1746-NIO4V SLC 500 Analog Input/Output Module is designed for space-efficient installations. This module is an indispensable tool for optimizing your industrial automation processes, delivering enhanced performance and efficiency.
