ABB IMAS102 Analog Input Module

Analog Input Channels:16

Signal Range:-10V to +10V or 0V to 10V

Sampling Rate:Up to 1 kHz

Power Consumption:Max 20 mA

Operating Temperature:-20°C to +70°C

Enclosure Type:IP20

Communication Interface:MODBUS RTU

    The ABB IMAS102 Analog Input Module is engineered to provide unparalleled precision and accuracy in industrial applications. This module is designed for seamless integration into complex control systems, ensuring reliable data acquisition under various operational conditions.

    With a wide input range of -10V to +10V, the IMAS102 is suitable for a broad spectrum of industrial measurement tasks, including temperature, pressure, and flow monitoring.

    Featuring a sampling rate of up to 1 kHz, this module ensures real-time data processing, critical for applications requiring fast response times and dynamic control adjustments.

    Operable within an expansive temperature range from -25°C to +85°C, the IMAS102 maintains optimal performance across diverse environmental conditions, making it ideal for outdoor and extreme condition applications.

    The low power consumption of ≤ 1W makes it energy-efficient, reducing operational costs without compromising on functionality. It supports both 2-wire and 4-wire connection types, offering flexibility in system design.

    Equipped with Modbus RTU protocol compatibility, the IMAS102 ensures seamless communication with a wide array of industrial automation systems, enhancing interoperability and system scalability.
