FS225R12KE3/AGDR-71C – ABB Module

Manufacturer:ABB

Model Number:FS225R12KE3/AGDR-71C

Module Type:IGBT

Power Rating (kW):225

Peak Current (A):1200

Operating Temperature Range:-40°C to +150°C

Cooling Method:强迫风冷

Insulation Resistance (MΩ):≥500

Certification:CE, UL

Dimensions (WxHxD):300mm x 200mm x 120mm

Weight (kg):10.5

Operating Voltage (V):DC 600V to DC 1700V

Operating Frequency (kHz):0 to 150kHz

Control Interface:RS485, CANopen

    The ABB FS225R12KE3/AGDR-71C IGBT module is engineered to withstand the rigors of industrial settings, offering unparalleled reliability and efficiency. Its compact size and high power density make it an optimal choice for space-constrained industrial machinery.

    With a power rating of 1200V and 225A, this module is capable of handling high-power loads while maintaining exceptional thermal management through its robust heat dissipation design. This ensures continuous operation under extreme conditions without compromising on performance.

    Equipped with state-of-the-art semiconductor technology, the FS225R12KE3/AGDR-71C boasts a wide operating temperature range from -40°C to +125°C, allowing it to function reliably in various industrial climates. Its high insulation resistance further enhances its durability and safety in harsh environments.

    Featuring a switching frequency of up to 71kHz, the module delivers fast response times, essential for precision control in industrial processes. Its IP20 protection level ensures adequate protection against dust and splash water, ensuring uninterrupted operation even in challenging industrial settings.

    Certified to international standards such as CE, UL, and CSA, the ABB FS225R12KE3/AGDR-71C is a testament to ABB‘s commitment to quality and safety. It is backed by comprehensive documentation and support, providing peace of mind for customers seeking a reliable and efficient solution for their industrial control needs.
