Operating Voltage:24V DC
Current Consumption:Max 50mA
Operating Temperature Range:-20°C to +60°C
Storage Temperature Range:-40°C to +70°C
Communication Interface:RS485
Protocol Compatibility:Modbus RTU
Input/Output Configuration:2x Analog Input, 1x Analog Output
Relay Outputs:4x SPDT
Power Supply:Separate Power Supply Required
Dimensions:148.5mm x 92mm x 51mm (LxWxH)
Weight:Approx. 150g
The ABB ABSDP-PDP-3 PCB CARD is engineered with precision for industries demanding high reliability and efficiency. This card supports a wide range of applications from manufacturing processes to process control, ensuring smooth operation even in challenging environments.
Equipped with two high-precision analog inputs, this module allows for accurate data acquisition, crucial for monitoring and controlling critical parameters in industrial operations. Its single analog output ensures precise control over actuators or other equipment.
Featuring four SPDT relay outputs, the card provides versatile control options for switching or signaling tasks. These relays can be used for a variety of functions, including but not limited to, alarm systems, safety mechanisms, or process control adjustments.
With its ability to communicate via RS485 using Modbus RTU protocol, the ABB ABSDP-PDP-3 PCB CARD seamlessly integrates with existing control networks, facilitating easy setup and maintenance. This compatibility ensures a smooth transition and expansion within existing automation systems.
Engineered for longevity, this module operates efficiently within a broad temperature range, ensuring it remains functional in diverse industrial climates. The separate power supply requirement ensures stability and prevents any disruptions caused by power fluctuations.
