AB MicroLogix 1762-IR4 RTD Input Module – Industrial Automation Solution

Module Type:Discrete Input Module

No. of Inputs:4

Voltage Category:24VDC

Input Resistance:400 Ohms

Operating Temperature:-25°C to 60°C

Power Consumption:<= 5 W

Dimensions:100mm x 50mm x 35mm

Weight:0.25kg

Mounting:Panel or DIN Rail

    Integrating advanced RTD (Resistance Temperature Detector) technology, the Allen-Bradley 1762-IR4 MicroLogix RTD Input Module is specifically crafted for applications requiring precise temperature measurements in harsh industrial environments.

    This module is equipped with four high-precision RTD channels, enabling accurate temperature sensing across a wide range from -200°C to +850°C. It ensures exceptional measurement accuracy within ±0.1% of full scale, crucial for industries where temperature control is paramount.

    Featuring an efficient power consumption of ≤15W, this module optimizes energy use without compromising on performance. Its compact design allows for easy installation via DIN Rail mounting, making it highly adaptable to various industrial setups.

    With its compatibility with MicroLogix systems, the 1762-IR4 seamlessly integrates into existing automation networks, facilitating streamlined data acquisition and processing. This integration is further enhanced by its internal web server, providing access to comprehensive documentation, real-time module status, diagnostics, and firmware updates.

    For added convenience and robustness, the module utilizes a personality module—a non-volatile industrial-grade Compact Flash (CF) card—to store critical network and module configurations. This feature ensures quick recovery and easy disaster management, safeguarding against data loss in case of system failures.
