Type:PCB Gate Drive Board
Model Number:1336-BDB-SP18D
Power Rating:Up to 1800W
Operating Voltage:12-30V DC
Operating Current:100A
Maximum Pulse Frequency:20kHz
Switching Technology:MOSFET-based
Input Signal Type:Digital or Analog
Environmental Temperature Range:-40°C to +85°C
Dimensions (LxW):150mm x 100mm
Mounting Type:Panel Mount
Certifications:UL, CE, RoHS
The AB 1336-BDB-SP18D PCB module is specifically engineered for applications requiring robust gate drive performance in challenging environments. Its advanced semiconductor technology ensures long-lasting reliability and efficiency.
This module supports a wide operating temperature range from -40°C to +85°C, making it suitable for various industrial settings. It can handle input voltages from 10V to 40V DC, providing versatility in different power supply scenarios.
With a continuous output current of 10A and peak current capacity of 20A, the 1336-BDB-SP18D is capable of driving high-power devices with precision. Its high switching frequency of up to 20 kHz enables fast response times, enhancing system performance.
Equipped with superior insulation resistance, the module ensures safe operation and minimizes the risk of electrical interference. This feature is crucial for maintaining system integrity and preventing unexpected failures.
Designed with ease of integration in mind, the AB 1336-BDB-SP18D PCB module is compatible with a broad range of industrial automation systems. Its compact size and standardized pinout facilitate seamless installation and configuration.
