AB 1756-IF6CIS Analog Input Isolated Current Module, High Precision Control Solutions

In stock

The AB 1756-IF6C is an isolated current analog input module designed for precise data acquisition in harsh industrial environments. It offers enhanced noise immunity and supports multiple current inputs, making it ideal for applications requiring high accuracy and reliability.

Measurement Range:4 mA to 20 mA

Input Type:Isolated Current

Resolution:0.02 mA

Accuracy:+/- 0.02% of full scale + 2 LSB

Power Supply:12 to 36 VDC

Communication Interface:ControlNet

Environmental Conditions:Temperature range: -40°C to 85°C, Humidity: 5 to 95% non-condensing

Enclosure Rating:IP20

Operating Voltage:24 VDC

Output Signals:4 to 20 mA, 0 to 10 V

Operating Frequency:50 Hz

Communication Rate:500 kbps

Dimensions:90 x 90 x 65 mm

Weight:0.2 kg

The AB 1756-IF6CIS Analog Input Isolated Current Sensor is engineered for critical industrial applications where accurate current measurement is essential. It offers unparalleled precision with a wide measurement range from 4 mA to 20 mA, ensuring reliable data collection even in demanding environments.

Featuring an isolated current input design, this sensor prevents electrical interference, ensuring stable readings in harsh industrial conditions. Its high accuracy of +/- 0.02% of full scale plus 2 Least Significant Bits (LSBs) makes it ideal for applications requiring meticulous monitoring and control.

Operated with a power supply of 12 to 36 Volts Direct Current (DC), the sensor ensures robust performance across various industrial setups. Equipped with a ControlNet communication interface, it seamlessly integrates into advanced automation systems, facilitating efficient data exchange and control.

Designed to withstand a broad temperature range from -40°C to 85°C, coupled with a humidity tolerance of 5 to 95% non-condensing, the AB 1756-IF6CIS ensures reliable operation in diverse environmental conditions. Its compact IP20 enclosure not only protects against dust and splashes but also maintains a neat workspace.

With its 24 Volt DC operating voltage, the sensor is compatible with a wide range of industrial systems. It provides versatile output signals, either as 4 to 20 mA or 0 to 10 Volt, enabling seamless integration into different control strategies. Additionally, the sensor supports a communication rate of up to 500 kilobits per second, ensuring quick and efficient data transmission.
