Manufacturer:Allen Bradley
Model:1756-IF16H
Module Type:Analog Input
Channels:16
Differential Voltage/CURRENT Input:Yes
Data Formats:Choice of three
Input Ranges:Multiple current and voltage options
Module Filter:Standard
Real-time Sampling:Yes
Fault Detection:Under range, over range
Process Alarms:Rate, wire-off
Communication Protocol:HART
Power Consumption:6.2 Watts
Temperature Range:0 – 60 DEG C
Environmental Conditions:5 – 95% Non-Condensing Relative Humidity
Vibration Resistance:2 G
Shock Resistance:30 G
Connection:Ethernet/IP Bridge
Ethernet Compliance:802.3
USB Port:Included
Power Supply:3 MA At 24 VDC
Mounting:Chassis
Communication Speed:10/100 MBPS
Enclosure Type:Open Type
Isolation:30 V Continuous
The 1756-IF16H ControlLogix Analog Input Module is a high-performance component designed for seamless integration into complex industrial control systems. It offers exceptional accuracy and reliability, making it ideal for applications requiring precise data acquisition, such as process control, machine monitoring, and quality assurance.
Featuring advanced signal processing capabilities, this module ensures reliable data transmission over DeviceNet or EtherNet/IP networks, enhancing system interoperability and reducing the complexity of integration. Its wide operating range, from 4 to 20 mA or 0 to 10 V, accommodates various sensor inputs, enabling flexible deployment across different industries.
With a compact design that measures 104 mm x 90 mm x 30 mm and weighs only 0.2 kg, the 1756-IF16H is highly portable and can be easily installed in tight spaces without compromising performance. The module is equipped with robust environmental protections, ensuring it performs reliably in harsh industrial settings with temperature ranges from -10°C to +55°C and humidity levels up to 95% RH without condensation.
For enhanced user convenience and system maintenance, the 1756-IF16H comes with a modular design, allowing for easy replacement and upgrade without disrupting ongoing operations. Its compatibility with a wide range of communication protocols, including DeviceNet and EtherNet/IP, facilitates seamless integration with other Rockwell Automation components and third-party devices, optimizing system scalability and flexibility.
To meet stringent industry standards, the 1756-IF16H is certified by UL and CE, ensuring its safety and reliability. This certification guarantees that the module adheres to international safety and quality standards, providing peace of mind for users in various sectors.
