AB 1756-CN2R/B ControlNet Redundant Bridge Module

Model Type:ControlNet Redundant Bridge Module

Manufacturer:Allen-Bradley

Module Number:1756-CN2R/B

Network Compatibility:ControlNet

Redundancy:2-way Redundant

Input Capacity:Multiple configurable inputs

Operating Temperature Range:-40°C to +70°C

Power Consumption:≤ 1.5 W

Dimensions:89.5 mm x 68.8 mm x 34.9 mm

Mounting:Panel Mount

Enclosure:IP20

Communication Interface:RS-485/422

Data Rate:Up to 1 Mbps

Protocol Support:ControlNet, Ethernet/IP, Modbus/TCP

    This ControlNet Redundant Bridge Module from Allen-Bradley ensures high network availability and fault tolerance in demanding industrial environments. It supports multiple configurable input types, allowing for versatile integration into various automation systems.

    Featuring a compact design and IP20 enclosure, it is suitable for both indoor and outdoor installations, offering reliable operation across a wide temperature range. Its low power consumption minimizes energy costs without compromising performance.

    With support for both ControlNet and Ethernet/IP protocols, along with Modbus/TCP, this module seamlessly integrates with a wide array of industrial equipment, enhancing system flexibility and efficiency.

    The 2-way redundancy feature ensures continuous operation even if one connection fails, significantly reducing downtime and improving overall system reliability.

    Ideal for applications requiring high-speed data transmission and robust network architecture, the Allen-Bradley AB 1756-CN2R/B ControlNet Redundant Bridge Module is a critical component for advanced industrial automation solutions.
