AB 1756-CN2R/B ControlLogix ControlNet Redundant Bridge Module

Model Type:Redundant Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-CN2R/B

Communication Interface:ControlNet

Number of Channels:2

Current Rating:Drawn: 970 MA at 5.1 VDC, 1.7 MA at 24 VDC

Isolation:30 V (Continuous), Basic Insulation Type

Mounting:Chassis

Enclosure Type:Open Type

RFI Suppression:Radiated: 10 V/M with 1 KHZ sine-wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 900 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 1890 MHz, 3 V/M with 1 KHZ sine-wave 80% AM from 2000 – 2700 MHz

Temperature Rating:32 – 140 DEG F

Operating Voltage:Not specified

    Engineered for industrial strength and durability, the Allen-Bradley 1756-CN2R/B ControlLogix ControlNet Redundant Bridge Module boasts a robust design that withstands harsh environments commonly found in manufacturing facilities. This module is specifically crafted to facilitate efficient data exchange between ControlLogix processors and ControlNet devices, ensuring smooth operation and enhanced system reliability.

    Featuring redundant functionality, this module provides an extra layer of security by maintaining communication integrity even in the event of a single point failure. Its advanced isolation technology ensures that each channel operates independently, minimizing the risk of cross-channel interference and enhancing overall system stability.

    The open-type enclosure design allows for easy installation and maintenance, making it a preferred choice for retrofit applications or new installations. With its compact size and modular architecture, this module seamlessly integrates into existing ControlLogix systems, enabling quick setup and deployment.

    Designed with user convenience in mind, the 1756-CN2R/B ControlLogix ControlNet Redundant Bridge Module comes equipped with intuitive configuration tools that allow for easy setup and monitoring through standard industrial interfaces. Its compatibility with Allen-Bradley’s comprehensive software suite further simplifies system integration and management.

    Certified for safety and reliability, this module meets stringent industry standards and regulations, ensuring that your automation systems operate within safe parameters. Backed by Allen-Bradley’s reputation for quality and support, you can trust this module to deliver consistent performance and minimize downtime.
